EzCiclo Key Material Licensing
RSE100
Description
EzCiclo Key Material- Features
- Process: Prepreg
- Epoxy Equivalent Weight: 220-320 (g/eq)
- Viscosity (cps): 1,000-3,000 (70℃)
- Recommended Ratio: >10%
Product Profile
| Application | Addition Ratio | Viscosity (70°C) | Gel Time (150°C test with Rheometer) | Tg-DSC |
|---|---|---|---|---|
| Prepreg | 10% | 28,000-38,000 cps | 3-8 mins | 120-130°C |
Equivalent Mechanical & ILSS Performance to Existing Commercial Prepreg
| Property | Commercial Prepreg/T700/FAW100/RC37% | EzCiclo RB564 /T700/FAW100/RC37% | Test Method |
|---|---|---|---|
| 0°Tensile Strength (MPa) | 2337 | 2468 | ISO 527-5 |
| 0°Tensile Modulus (GPa) | 116 | 109 | ISO 527-5 |
| 0°Compressive Strength (MPa) | 945 | 898 | ISO 14126 |
| 0°Compressive Modulus (GPa) | 110 | 105 | ISO 14126 |
| 90°Tensile Strength (MPa) | 73 | 65 | ISO 527-5 |
| 90°Tensile Modulus (GPa) | 7 | 7 | ISO 527-5 |
| 90°Compressive Strength (MPa) | 172 | 174 | ISO 14126 |
| 90°Compressive Modulus (GPa) | 8 | 8 | ISO 14126 |
| ILSS (MPa) | 96 | 89 | ISO 14130 |
